DP Male to DVI Female Adapter

Description

Displayport male to HDMI Female  adapter

1). DisplayPort version 1.2 supports 1.62 and 2.7Gbps transmission bandwidths

      HDMI resolution up to 1920 x 1080/60Hz,Transmission distance can be up to 3 m

2). Supports up to 1920 x 1200 DVI-D/VGA resolution 60Hz,Conform to the VESA standard

3). 2.25Gbps/225MHZ HDMI video supports for each channel transmission bandwidths

4). DVI-D video support for 2.7Gbps/270MHZ per channel transfer bandwidth,

     Supports color depth of each channel 12bit HDMI/DVI-D

     HDMI support for 5.1-channel transfer (for MAC)

5). input interface: Mini DisplayPort 20pin male

6). output interface: HDMI/DVI-D/VGA (Note: only one interface can output the same time)

7). operating temperature: 0 ° c to +70 ° c

8). operating humidity: 10% to 85% RH

9).Support for TMDS on/off power-save mode is enabled

      Direct link, direct use, do not need to make any setting, convenient

      length: 15cm

10).The resolution of the output interface:

       HDMI:480i, 480p, 576i, 576p, 720p, 1080i, 1080p

       DVI-D:1280 x 1024, 1360 x 768, 1920 x 1080, 1920 x 1200

       VGA:1024 x 768,1280 x 1024, 1680 x 1050, 1920 x 1080, 1920 x
